BOLTRACK BAR BENDING MACHINE

1.Totally enclosed reduction gearbox separated from working disk.
2.Gear and gear shaft are made by high quality structural steel under heat treatment.
3. Totally adopted roller bearings featured with flexible rotation and little attrition.
4. Brake motor ensure the accuracy of the bending angle in case of sudden stopping and restarting.
5. Insert pins that placed the holes located around the turning table and the adjustable square steel.
6. Articulated type motor is convenient and fast to adjust. Adjustable working speed meet the requirement of bending different rebar.
7. Emergency stop button and reversing device in case of misuse

Bending Capacity                (ub≤450MPa)6--45mm
	                        (ub≤650MPa)6--38mm
Working Speed	 	        12R/Min(High speed)
				8R/Min(Low speed)
Input Voltage			415V
Power of Motor		        3Kw-4P
Overall Dimension(mm)	        860x820x910
Net Weight			380Kg
Packing Size(mm)		1020x980x1040
Operating Type		        Automatic	(brake motor)



BOLTRACK BAR CUTTING MACHINE

1.The main structure is made by high strength nodular iron casting casted on the temperature of1400 ℃
2.The gear is made by high quality structure steel, teeth under high frequency ac treatment.
3.Rust prevention and cleaning to the casting before installation.
4.Grade8.8 high-strength screws(σbmin.d≤16mm 800Mpa;d>16mm,830Mpa).
5.enclosed pully cover,Adjustable rebar fixture and cutter hood.
6.4-degree driving mechanism,more powerful and higher efficiency.
7.Inner pedal ,rebar shelf and cutter hood ro ensure safe operation.

Cutting Capacity		(ub≤450MPa)6--45mm
				(ub≤650MPa)6--38mm
Cutting Frequency		50times/min
Input Voltage			415V
Power of Motor			3Kw-2P
Overall Dimension(mm)		1100x485x850
Net Weight			450Kg
Packing Size(mm)		1280x585x910



BOLTRACK SPIRAL RING MACHINE

1.The working disk is inserted into the working table which made the external appearance pleasant at sight and the operation easier to handle.
2.GEAR, WORKING DISK, STOP GAUGE and PILE HEAD are made of high quality alloy steel which has undergone the required heat treatment (quenching, tempering or high frequency), this is in order to make sure that the important components can ensure reliable operation also under heavy load conditions and guarantee long-lasting working life.
3.Totally adopt bearing type featured with flexible movement.
4.Featured with large moment of force, fast return speed, and over-load protection.
5.Apply full mechanical linking to control hydraulic operation, featured with accurate operation, long service life, fast speed and accuracy.
6.Adopt both manual and automatic controlled transform way, which convenient for usage.
7.Bending angle can be adjusted from 0°to 210°.

MODEL			GWH-32E
MOTOR POWER		3 kw-4p
SYSTEM			Electric motor
ROTATION SPEED 		15r/min (adjustable)
BENDING CAPACITY	Plain Bar Upto  32mm /  TMT Bar Upto    30mm
WEIGHT			340 Kg



BOLTRACK STIRRUP BENDER MACHINE

1.Totally open reduction gearbox seperated from bending wheel.
2.Gear and gear shaft are made by high quality structure steel under heat treatment.
3.Totally adopted roller bearing feartured with flexible rotation and little attrition.
4.Emergency stop button and reversing device in case of misuse.

Bending Capacity  		(ub≤450MPa)4--26mm
				(ub≤650MPa)4--22mm
Working Speed  	                32R/Min(90°)
				28R/Min(135°)
Input Voltage			415V
Power of Motor		        3Kw-4P
Overall Dimension(mm)    	150x550x870
Net Weight			190Kg
Packing Size(mm)		1310x710x970
Operating Type		        Manual
